Quincy Compressor QT-10 Two Stage Piston Air Compressor 10 HP 200 Gallon Duplex Pro 230V 3 Phase New
Product Overview
The Quincy Compressor QT-10 is a two-stage piston air compressor featuring a duplex configuration and a 10 HP rating. With a capacity of 70 ACFM and a pressure rating of 175 PSI, it pairs substantial airflow with high-pressure capability. A 200-gallon horizontal tank provides air storage in a horizontal layout. The compressor uses splash lubrication and is supplied in the Pro package configuration with automatic tank drain, overload protection, and low oil level shutdown.. Electrical specifications are 230/3/60.
Brand new
1 year factory warranty
Manufacturer direct shipping from AL & NC
Authorized Quincy Compressor dealer
Features
- Splash Lubricated
- Cast-iron Crankcase, Cylinders and Flywheel
- Stainless-Steel Reed Valves with Valve Bumpers
- Ductile Iron, Double Throw Crankshaft
- Industrial Ball Bearings
- Two-Piece Aluminum Connecting Rods
- Fin and Tube Intercooler
- Automotive Style Inlet Filter/Silencer
- Motor Overload Protection
- Automatic Tank Drain
- Dual Control on 10-15 HP
- Low Oil Level Shutdown
Specifications
| Configuration | Duplex |
|---|---|
| Horsepower | 10 HP |
| Capacity | 70 ACFM |
| Package | Pro |
| Tank Size and Orientation | 200 gallon, horizontal |
| Voltage | 230/3/60 |
|---|---|
| Pressure | 175 PSI |
Warranty
This item comes with a 1 year factory warranty.
