Grizzly G1033Z Benchtop Planer 20" 5 HP New
Product Overview
The Grizzly G1033Z is a heavy-duty 20-inch benchtop planer designed to flatten and dimension rough lumber with power and consistency. Its 5 HP motor drives a 4-knife cutterhead at 5000 RPM, giving woodworkers the capacity to handle wide boards, demanding stock removal, and smooth finish passes.
Built for serious woodworking, it features precision-ground cast-iron tables with long 58-inch overall support, adjustable bed rollers, and two feed speeds for rough and finish planing. The triple-belt drive helps deliver strong, steady power, while the 5-inch dust port and chip deflector help keep chips moving away from the cutting area.
This planer is a strong fit for dedicated hobbyists, small professional shops, and woodworkers who regularly work with hardwoods or wider stock. With an 8-inch maximum stock thickness and durable high-speed steel knives, it is made for users who want accurate, repeatable results on furniture parts, panels, and general milling work.
Brand new
1 year factory warranty
Manufacturer direct shipping from MO & WA
Authorized Grizzly dealer
Features
- Precision-ground cast-iron table and extension wings
- Board return rollers
- Adjustable bed rollers
- Magnetic switch with thermal overload protection
- Two feed speeds for rough and finish planing
- Triple belt drive
- Anti-kickback fingers
- Powder coated finish
Specifications
| Motor | 5 HP, 230V, single-phase, 23A |
| Maximum stock width | 20" |
| Maximum stock thickness | 8" |
| Minimum stock thickness | 1/4" |
| Minimum stock length | 7" |
| Maximum cutting depth full width | 3/32" |
| Maximum cutting depth 6" wide board | 1/8" |
| Cutterhead diameter | 3-1/4" |
| Cutterhead type | 4-knife |
| Knife size and type | 20" x 1" x 1/8", HSS |
| Cutterhead speed | 5000 RPM |
| Feed rate | 16, 28 FPM |
| Table size with extensions | 20" x 58" |
| Dust port size | 5" |
| Footprint | 22" x 28" |
| Overall dimensions | 39" W x 58" D x 41" H |
| Approximate shipping weight | 820 lbs. |
Warranty
This item comes with a 1 year factory warranty.
