Ekko Lithium Walkie Stacker Counterbalanced Side-Shift 189" Lift 3,000 lbs. Capacity EK14CS-189Li New
Product Overview
The EKKO EK14CS-189Li Lithium Walkie Stacker is designed to combine the versatility of a forklift and walkie stacker. This stacker features side-shifting and adjustable width forks with forward/backward tilt, allowing for precise material positioning. It offers a strong load capacity of 3,000 lbs. and can lift up to 189 inches. Constructed from high-quality steel and robust components to withstand challenging conditions. Perfect for loading and unloading trucks, operating in loading docks, manufacturing floors, and warehouses.
Brand new
3 year limited warranty
Ships from manufacturer in CA
Fast processing with free shipping
Authorized Ekko dealer
Features
- 3,000 lbs load capacity
- 189" Lift Height (15.75 ft)
- Side-Shifting
- Adjustable Forks 8.6"-26"
- Fork Length 42.1"
- Tilt 2/5 Degree
- Curtis Controller
- Polyurethane Wheels
- Ergonomic Handle and Controls
- Steel Construction
- Robotic Welding
- Battery and Charger Included
Specifications
| Model | EK14CS-189Li |
| Load Capacity | 3,000 lbs |
| Lifting Height Max | 189" |
| Load Center | 24" |
| Wheelbase | 47" |
| Side Shifting | 4" |
| Tire Material | PU |
| Mast Tilt (Forward/Backward) | 2° / 5° |
| Lowered Mast Height | 84.3" |
| Extended Mast Height | 217.2" |
| Fork Adjust Width | 8.6" - 26" |
| Fork Size | 42.1" x 4" x 1.4" |
| Turning Radius | 57" |
| Lift Speed (laden/unladen) | 2.95 / 3.94 in/s |
| Lowered Speed (laden/unladen) | 5.3 / 4.7 in/s |
| Drive Motor | 2.5kW |
| Lift Motor | 2.5kW |
| Battery | 24V / 150Ah |
| Overall Dimensions | 122.6" x 42.1" x 84.3" |
| Weight | 4,650 lbs |
Package Contents
Ekko EK14CS-189Li Lithium Counterbalanced Walkie Stacker
Battery
Charger
Manual
Warranty
This item comes with a 3 year limited warranty on parts, and 1 year battery warranty.
