Between fork backrest and front wheel (Inch)
|
7.56 |
Wheelbase (Inch)
|
53.46 |
Service weight with battery
|
6600 lbs. |
Wheels type
|
PU |
Driving wheel size (Inch)
|
Φ9.84 × 5 |
Bearing wheel size (Inch)
|
Φ5.9 × 3.23 |
Wheels, number front/rear
|
1, /2 |
Track width (Inch)
|
37.8 |
Lowered mast height (Inch)
|
93.11 |
Lifting height (Inch)
|
196" |
Extended mast height (Inch)
|
285 |
Height of overhead guard (Inch)
|
89.48 |
Height of seat/stand-on platform (Inch)
|
10.67 |
Additional lift height (Inch)
|
30.71 |
Total lift height (Inch)
|
227 |
Platform lifting height (Inch)
|
206.873 |
Lowered fork height (Inch)
|
1.97 |
Picking height (Inch)
|
258.01 |
