Ekko EK14S-130 Walkie Stacker 3300 lbs. Capacity 130" Lift Height Counterbalanced Side-Shifting New
Product Overview
The EKKO EK14S-130 is a fully powered counterbalanced walkie stacker with side-shifting capability for efficient material handling in warehouses, stock rooms, loading docks, and manufacturing floors. It combines forklift-like versatility with the compact maneuverability of a walkie stacker for loading, unloading, stacking, and transport tasks. This unit features electric lift and drive systems, adjustable forks, EPS electronic power steering, and durable steel construction. Polyurethane wheels, an ergonomic control handle, and included battery and charger support dependable day-to-day operation. Its compact footprint and 130" lift height make it well suited for tight aisles and demanding indoor applications.
Brand new
3 year limited warranty
Manufacturer direct shipping from California
Authorized EKKO dealer
Features
- Load Capacity 3300 lb
- Raised Height 130" (10.83ft)
- SIDE-SHIFTING
- Adjustable Forks 8.6-28.3"
- Fork Length 45.3"
- Tilt 2/5 Degree
- Curtis Controller
- 24V AC Drive Motor
- 24V Lift Motor
- EPS (Electronic Power Steering)
- Polyurethane Wheels
- Ergonomic Handle and Controls
- Steel Construction
- Robotic Welding
- Charger Included
- Batteries Included
Specifications
| Model | EK14S-130 |
| Product Type | Counterbalanced Walkie Stacker |
| Lift | Electric |
| Drive | Electric |
| Load Capacity | 3300 lbs |
| Load Center Distance | 24" |
| Wheel Base | 47" |
| Lifting Height | 130" |
| Side-Shifting | 4" |
| Lowered Mast Height | 84" |
| Extended Mast Height | 167" |
| Mast/Fork Carriage Tilt Forward/Backward | 2/5° |
| Overall Length | 109" |
| Overall Width | 39" |
| Fork Size Thick/Width/Length | 1.4" / 4" / 45.3" |
| Fork Adjust Width | 8.6"-28.3" |
| Turning Radius | 57" |
| Max Gradient Performance Laden/Unladen | 6/10% |
| Lift Speed Laden/Unladen | 4 / 5.1 in/s |
| Lowering Speed Laden/Unladen | 5.3 / 4.7 in/s |
| Charger | 24V/30A |
| Driving Motor | AC 24V/2500W |
| Lifting Motor | 24V/2500W |
| EPS Steering Motor | 24V/200W |
| Battery Voltage | 24V/210Ah |
| Service Weight | 3840 lbs |
| Dimensions | 109" L x 39" W x 84" H |
Package Contents
EKKO EK14S-130 counterbalanced walkie stacker
Battery
Charger
Warranty
This item comes with a 3 year warranty.
