Cummins C175D6D 175kW Agricultural Generator Diesel Liquid Cooled 1 Phase 120/240V No Enclosure A061T476 New
Product Overview
The Cummins C175D6D is a 175kW generator built for standby power in demanding agricultural environments. It features a heavy-duty 6.69L 4-cycle diesel engine, a 4-pole brushless alternator, and PowerCommand 1.1 electronic controls for dependable operation and system integration. The standard cooling system supports operation in temperatures up to 122°F and includes coolant heaters for cold-weather starting down to -40°F. This model ships without a fuel tank and without an enclosure, and is rated for standby power applications only.
Not for sale in California.
2 year factory warranty
Brand new in box
Manufacturer direct shipping
Authorized Cummins dealer
Features
- Robust product design and testing - The generator is designed to operate under extreme environmental conditions. The generator is tested and certified per the latest EPA and UL standards.
- Heavy duty engine - Rugged 4-cycle industrial diesel delivers reliable power and fast response to load changes.
- Alternator - Several alternator sizes offer selectable motor starting capability with low reactance 2/3 pitch windings, low waveform distortion with non-linear loads and fault clearing short-circuit capability.
- Control system - Provides total generator set system integration including automatic remote starting/stopping, precise frequency and voltage regulation, alarm and status message display, output metering, auto-shutdown at fault detection and NFPA 110 Level 1 compliance.
- Cooling system - Standard cooling package provides reliable running at up to 50 °C (122 °F) ambient temperature. Coolant heaters also come standard on generator sets for starting well below freezing.
- Battle Short Mode – This mode will allow the generator to override certain faults that would normally shut the generator down.
- Flexible exercise mode - The innovative, flexible exercise mode enables the generator to exercise at a time, frequency and duration that suits the customer's preference reducing unnecessary fuel consumption, emissions and noise.
- Self-diagnostics and easy service - The generator is equipped with Cummins PowerCommand® electronic control to provide industry-leading self-diagnostic capabilities. In addition, critical components of the generator are designed to ensure service and preventive maintenance can be completed in a short period of time
Specifications
| Model Number | C175D6-A061T476 |
|---|---|
| Rated Output | 175kW |
| Voltage | 120/240V |
| Phase | Single Phase |
| Circuit Breaker | 800A |
| Fuel Type | Diesel |
| Engine | QSB7 |
| Engine Displacement | 6.69L |
| Engine Type | 4-cycle inline |
| Rated Engine Speed | 1800 RPM |
| Alternator Type | 4-pole brushless revolving field |
|---|---|
| Control System | PowerCommand 1.1 |
| Fuel Tank | Required, Not included |
| Enclosure | None |
| Dimensions | 113 x 40 x 56 in |
| Weight | 3179 lbs |
Package Contents
Cummins C175D6D 175kW Agricultural Generator
Warranty
This item comes with a 2 year factory warranty.
