Benefits of Short Distance Projection
Minimum Space ConstraintsImagine the freedom of having the same large size image from just half the traditionally required throw distance! Having increased placement flexibility and more efficient use of available space. That's the magic of short-throw! Zero Eye-Blinding LightsThe short-throw projection distance keeps the projector light from shining directly into your eyes, allowing you to keep your focus on your audience. Zero DisruptionsWith a projection distance this close, you will be able to move freely, without casting distracting shadows on the screen! |
Brilliant Image Performance
High Contrast
High contrast ratio adds depth to an image and is essential to provide crisp image detail. The high contrast ratio in the MW632ST helps produce images with stunning clarity and fine detail for sharper, easier to read text, graphics and video for more memorable presentations.
High Brightness
The high brightness of the BenQ MW632ST helps overcome most ambient light conditions to ensure your message will be seen clearly, even with the lights on.
Rich Connectivity
2 HDMI PortsCompatible with today's digital sources, the MW632ST provides Dual HDMI ports to satisfy your digital connectivity needs as well as dual VGA ports for traditional analog sources. |
|
Plug 'N Play, Enjoy Big Screen Fun from Your Android DevicesYou can now share content from your favorite MHL enabled devices on the big screen. The MHL functionality in the MW632ST allows you to display pictures, movies and games from MHL enabled Android devices to the big screen. |
|
1.5A USB Type-A Power SupplyPowering your peripheral devices such as Chromecast or Roku stick is easier than ever with the built-in power enabled USB port, providing up to 1.5 Amps of power to eliminate the need for external power connections. |
Ease of Use
Built-in SpeakersPowerful Built-in 10W speaker provides ample amplification to ensure your message is clearly heard. |
SmartEco™ Lamp Saving Technology
Incorporating BenQ's renowned SmartEco lamp saving Technology, the MW632ST not only offers greater energy savings, but continues to deliver amazing picture quality through this innovative technology. SmartEco mode is designed to use only the exact amount of lamp power a projector needs to deliver the best contrast and brightness performance. This feature enables the MW632ST to deliver uncompromised projection quality with the added benefit of reduced the total cost of ownership by extending the lamp life and lowering power consumption.
(Source: 2010 Philips white paper)
Eco Blank Mode
The Eco Blank feature allows users to blank or mute the projected image on the screen, affording privacy to search for files or documents while the desktop is not projected to the entire audience. When activated, Eco Blank automatically dims lamp power, therefore lowering total power consumption by up to 70%.
Specifications:
Model | MW632ST |
Projection System | DLP |
Native Resolution | WXGA (1280 x 800) |
Brightness* (ANSI Lumens) | 3,200 ANSI Lumens |
Contrast Ratio | 13,000:1 |
Display Color | 1.07 Billion Colors |
Lens | F= 2.6-2.78, f=10.2-12.24mm |
Aspect Ratio | Native 16:10 (5 aspect ratio selectable) |
Throw Ratio | 0.72~0.87 (87" ± 3% @ 1.36m) |
Image Size (Diagonal) | 60"~180" |
Zoom Ratio | 1.2:1 |
Lamp Type | 196W |
Lamp Mode (Normal/Economic/SmartEco/LampSave/LumenCare)* | 4,000/ 6,000/ 6,500/ 10,000 hours |
Keystone Adjustment | 1D, vertical ± 30 degrees |
Projection Offset | 105% ± 5% |
Resolution Support | VGA (640 x 480) to WUXGA_RB (1920 x 1200) * RB = Reduced Blanking |
Horizontal Frequency | 15KHz~102KHz |
Vertical Scan Rate | 24-120Hz |
Interface |
Computer In (D-sub 15pin) x 1 (Share with component) Monitor Out (D-sub 15pin) x 1 Composite Video In (RCA) x 1 S-Video In (Mini DIN 4pin) x 1 HDMI x 2 (One share with MHL2.0) Audio In (Mini Jack) x 1 Audio L/R In (RCA) x 1 Audio Out (Mini Jack) x 1 Speaker 10W x 1 USB (Type mini B) x 1 (Download & Page Up/ Down) USB (Type A) x1 (1.5A Power Supply) RS232 (DB-9pin) x 1 IR Receiver x 2 (Front + Top) |
Dimensions (W x H x D mm) | 287.3 x 114.4 x 232.6mm |
HDTV Compatibility | 480i, 480p, 576i, 567p, 720p, 1080i, 1080p |
Video Compatibility | NTSC, PAL, SECAM |
3D Support and Compatibility |
PC: 120Hz Frame Sequential 3D for resolutions up to WXGA, PC: 60Hz Top-bottom 3D for resolutions up to SXGA+ Video: 60Hz Frame Sequential 3D for resolutions up to 480i |
Weight | 2.6 kg (7.93lbs) |
Audible Noise (Normal/Economic Mode) | 33 / 28 dBA (Normal/ Economic Mode |
Power Supply | AC100V to 240V, 50Hz to 60 Hz |
Power Consumption | Normal 305W, Eco 220W, Standby < 0.5W |
On-Screen Display Languages | Arabic /Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages) |
Accessories (Standard) |
Remote Control w/ Battery Power Cord (by region) User Manual CD Quick Start Guide Warranty Card (by region) VGA (D-sub 15pin) Cable |
Accessories (Optional) |
Spare Lamp Kit:P/N: 5J.JAR05.001 Ceilling Mount:P/N:5J.J4N10.001 Remote Control P/N: 5J.J9V06.001 3D Glasses:P/N: 5J.J9H25.001 Carry bag:P/N: 5J.J3T09.001 |
